CS020 - DVI-D Socket to HDMI-A plug adapter

Connect a DVI cable (plug) to a HDMI-ready device (socket) with this adapter!
The HDMI/DVI adapter CS020 offers both, a HDMI-A plug and a DVI-D socket. Direct adaptation to HDMI/DVI-ready devices is possible with the CS020. The latest specifications of HDMI and DVI present the CS020 adapter as a reliable, space-saving and easily usable companion in digital adaptations. Alongside the cables, our adapters of the Cinema Series offer perfect handling due to practice-orientated development.

Zurück

Features
DVI Single Link (24+5) for resolutions up to WUXGA / 1920x1200
Gold plated precision contacts with designer connector
HDMI-A male to DVI-D Single Link (24+5) female
Optimal signal quality - Connection with high-quality PCB
Designer packaging optimised for Point-of-Sale environments

Zurück

Logistics Information
Product 1. Net Weight in Kg	0,03
Product 1. Gross Weight in Kg	0,07
Product 1. Length in cm	4,6
Product 1. Width in cm	4
Product 1. Height in cm	1,56
Packaging 1. Length in cm	8
Packaging 1. Width in cm	8
Packaging 1. Height in cm	2,5
Master Carton Length in cm	41
Master Carton Width in cm	39
Master Carton Height in cm	30

Product Information
Europeans Customs Tariff Nr.	85366990990
Country of Origin	China
Packaging Material	Plastic/Paper

VPE Information
Master Packaging Unit (pcs)	120
Secondary Packaging Unit (pcs)	10
Third Packaging Unit (pcs)	1

Zurück

Connections
Connector material	PVC
Contact material	24ct gold plated, long-life design
Connector 1	HDMI Type A Plug (19pin)
Connector 2	DVI-D Bcuhse (24+1pin)
Contacts	24ct gold plated, long-life design

Electric signal
Maximum pixel clock / bandwidth	WUXGA (1920x1200)
HDCP	Yes
EDID	Yes

Cable
Type	Adapter

Signal transmission
Supported standards	HDMI, DVI
Transmission modes	Digital video signals
Supported Colors	8 bit RGB/YUV, Deep Color, x.v.Color™
Further standards	FullHD (1080i/p), HD ready (720i/p), SDTV (480i/p)
